Caching Strategies

Caching is one of the highest impact optimizations you can make in any system. Cache is the short-term memory that makes everything fast.

The Story: The Sticky Note on Your Desk

You work in a large office. Every time you need a colleague’s phone number, you walk to HR, wait, find the file, and come back — 5 minutes. After repeating this a few times, you write it on a sticky note.

👉 That sticky note is your cache.

Cache = storing the result of an expensive operation nearby so you don’t repeat it

Why Caching Exists

Every database read has a cost:

Disk I/O
Network latency
Query execution

Without cache:
[User] → [App] → [DB] → [App] → [User]    (~10–100ms)

With cache:
[User] → [App] → [Cache] → [App] → [User] (<1ms)

👉 Massive latency reduction
👉 Massive database load reduction

The Three Laws of Caching

Cache hit = fast, miss = expensive
Cache stores only hot data
Invalidation is the hardest problem

Cache Hit Rate — The Most Important Metric

Cache hit rate = hits / (hits + misses)

Hit Rate	Meaning
> 99%	Excellent
90–99%	Good
70–90%	Needs improvement
< 70%	Cache is ineffective

👉 Even 1% miss at scale = huge DB load

Cache Layers

Browser Cache          ← HTML/CSS/JS, images (no server needed)
     ↓
CDN Cache              ← Static assets and API responses at edge
     ↓
Load Balancer Cache    ← Simple request deduplication
     ↓
Application Cache      ← In-process memory (HashMap, LRU cache)
     ↓
Distributed Cache      ← Redis/Memcached (shared across app servers)
     ↓
Database Buffer Pool   ← DB caches its own pages in RAM
     ↓
Disk Cache (OS)        ← OS caches disk reads in memory

In-process vs Distributed Cache

	In-process (local)	Distributed (Redis)
Speed	Fastest (nanoseconds)	Fast (microseconds, network)
Shared?	No — each server has its own	Yes — all servers share one cache
Survives restart?	No	Yes (with persistence)
Memory limit	Single server’s RAM	Clustered RAM (terabytes possible)
Use when	Static data, tiny datasets	Session data, shared state, horizontal scaling

Rule:

Single server → in-process cache (e.g., LRU cache in app memory)
Multiple servers → use Redis (because in-process cache creates inconsistency)

Cache-Aside (Lazy Loading) — The Most Common

Story: You (the app) check your sticky note first. If it’s there, done. If not, you go to the records room (DB), get the data, and write it on a new sticky note for next time.

READ:
1. App checks cache for key
2. HIT  → return cached value ✓
   MISS → query DB → store result in cache → return result

WRITE:
1. Update DB
2. Invalidate (delete) the cache key ← next read will repopulate

def get_user(user_id):
    # 1. Check cache
    cached = redis.get(f"user:{user_id}")
    if cached:
        return json.loads(cached)

    # 2. Cache miss — hit DB
    user = db.query("SELECT * FROM users WHERE id = ?", user_id)

    # 3. Populate cache with TTL
    redis.setex(f"user:{user_id}", 3600, json.dumps(user))

    return user

def update_user(user_id, data):
    db.update("UPDATE users SET ... WHERE id = ?", user_id, data)
    redis.delete(f"user:{user_id}")  # Invalidate cache

Pros:

Only requested data gets cached (no wasted memory)
Cache failures don’t break the app — just slower

Cons:

First request always slow (cache cold start)
Potential for stale data between write and invalidation

Use when: General-purpose, read-heavy workloads. Default choice.

Read-Through — The Cache Manages Itself

Story: You ask the cache for data. The cache itself goes to the DB on a miss — you never talk to the DB directly.

[App] → [Cache] → (hit) → returns data
           ↓ (miss)
          [DB]
           ↓
        [Cache] populates and returns

Difference from cache-aside: The cache library/service handles the miss logic, not your application code.

Tools: Some Redis client libraries support this. Managed services like DAX (DynamoDB Accelerator).

Pros:

Cleaner application code
Cache miss handling is abstracted

Cons:

First request is always slow
Less control over what gets cached

Write-Through — Always Stay In Sync

Story: Every time you update a record, you update BOTH the DB and the cache simultaneously. The cache is never out of date — for long.

WRITE:
1. App writes to CACHE first
2. Cache synchronously writes to DB
3. Returns success only after both writes complete

READ:
Always hits cache → always fresh data

Pros:

Cache is always consistent with DB
Reads are always fast (no cold start problem)

Cons:

Every write is slower (two writes instead of one)
Cache fills with data that may never be read (write-once, never-read data wastes memory)

Use when: Read-heavy systems where stale data is unacceptable.

Example: user’s own profile page.

Write-Behind (Write-Back) — High-Speed Writes

Story: You scribble on the sticky note instantly. At the end of the day, someone updates the official records. Your writes are fast, but there’s a delay before the official record is updated.

WRITE:
1. App writes to cache → returns SUCCESS immediately
2. Cache asynchronously writes to DB (buffered, batched)

READ:
From cache → always fast

Pros:

Extremely fast writes (no DB latency for the user)
Batch DB writes = fewer DB round-trips

Cons:

Risk of data loss if cache crashes before async write completes
Complex recovery logic needed

Use when: High-throughput write scenarios where occasional data loss is tolerable.

Example: social media like counts, view counters, gaming leaderboards.

Refresh-Ahead — The Proactive Cache

Story: Before your sticky note expires, someone proactively fetches the fresh data so you never experience a cold miss.

Cache detects that key "user:42" TTL expires in 30s
→ Proactively fetches fresh data from DB
→ Repopulates before TTL expires
→ User never sees a cache miss

Pros: No latency spikes from cold misses on popular keys
Cons: May refresh data that’s no longer needed (wasted DB calls)

Use when: Highly predictable access patterns (dashboards, popular product pages)

Which Strategy Should You Use?

Default: Cache-aside
Strict consistency: Write-through
High write load: Write-behind
Predictable reads: Refresh-ahead

👉 Most real systems = Cache-aside + TTL + invalidation

Cache Invalidation: The Hardest Problem

“There are only two hard things in Computer Science: cache invalidation and naming things.” — Phil Karlton

Invalidation = figuring out when cached data has become stale and needs to be removed/updated.

TTL (Time to Live)

Assign an expiry to every cache entry. After TTL, the key expires and the next read goes to DB.

redis.setex("product:1001", 3600, data)  # expires in 1 hour

TTL too short	TTL too long
Many cache misses → DB load spikes	Stale data served to users

Choosing TTL:

User sessions: 24–72 hours
Product catalog: 10–60 minutes
Live sports scores: 10–30 seconds
User’s own profile: 5 minutes or event-driven invalidation

Event-Driven Invalidation

Delete the cache key the moment underlying data changes.

# When order status changes:
def update_order_status(order_id, new_status):
    db.update("UPDATE orders SET status=? WHERE id=?", new_status, order_id)
    redis.delete(f"order:{order_id}")             # direct key
    redis.delete(f"user_orders:{order.user_id}")  # related collection

Pro: Cache is never stale
Con: You must know all cache keys affected by every write — this gets complex

Versioned Cache Keys

Instead of invalidating, use a new key. Old key becomes orphaned and expires naturally.

# Store version in DB or separate Redis key
version = redis.get("user:42:version") or 1

cache_key = f"user:42:v{version}"

# On update: increment version
def update_user(user_id):
    db.update(...)
    redis.incr(f"user:{user_id}:version")
    # Old versioned key will expire via TTL

Pro: Simple, atomic, no cache stampede
Con: Old keys waste memory until TTL expires

Cache Eviction Policies

When the cache is full, what gets kicked out?

Policy	How it works	Best for
LRU (Least Recently Used)	Evict the key not accessed for the longest time	General purpose — default choice
LFU (Least Frequently Used)	Evict the key accessed the fewest times	Long-term hot data retention
FIFO (First In, First Out)	Evict oldest-inserted key	Simple queues
Random	Evict a random key	Low overhead, unpredictable but cheap
TTL-based	Evict expired keys first	When TTLs are well-calibrated

Redis eviction policies: allkeys-lru (most common), volatile-lru (only keys with TTL), allkeys-lfu, noeviction (errors on full cache)

Cache Anti-Patterns

The Cache Stampede (Thundering Herd)

Problem: Popular key expires. Simultaneously, 1,000 requests miss the cache, all query the DB at the same time. DB melts.

T=3600s: "product:1001" TTL expires
T=3600s + 1ms: 1000 concurrent requests all get MISS
               1000 DB queries fire simultaneously
               DB falls over

Solutions:

Mutex lock: First miss acquires a lock, fetches from DB, populates cache. Others wait.

lock = redis.set("lock:product:1001", 1, nx=True, ex=5)  # 5s lock
if lock:
    data = db.fetch(...)
    redis.set("product:1001", data, ex=3600)
    redis.delete("lock:product:1001")
else:
    time.sleep(0.05)
    return get_from_cache("product:1001")  # retry

Probabilistic early expiration: Before TTL hits, probabilistically refresh. High-traffic keys refresh earlier.
Stale-while-revalidate: Serve the stale value while asynchronously refreshing it.

Cache Penetration — The Ghost Key Attack

Problem: Attacker (or bug) queries keys that will never exist (e.g., user:-1, product:99999999). Every request misses cache and hits DB.

Solution: Cache null values

result = db.query(user_id)
if result is None:
    redis.setex(f"user:{user_id}", 60, "NULL")  # cache the miss too
    return None

Or use a Bloom filter — a probabilistic structure that tells you “definitely not in DB” before even querying.

Cache Avalanche

Problem: Many keys expire at the same time (e.g., cache seeded in bulk → all expire in 1 hour). Massive DB spike.

Solution: Add jitter to TTLs.

import random
ttl = 3600 + random.randint(-300, 300)  # 3600s ± 5 minutes
redis.setex(key, ttl, value)

Redis: The Industry Standard

Redis (Remote Dictionary Server) is not just a cache — it’s an in-memory data structure store.

Data structures

Type	Commands	Use case
String	GET, SET, INCR, EXPIRE	Cache, counters, rate limiting
Hash	HGET, HSET, HMGET	User objects, shopping carts
List	LPUSH, RPUSH, LRANGE	Queues, activity feeds
Set	SADD, SMEMBERS, SINTER	Unique visitors, tags
Sorted Set	ZADD, ZRANGE, ZRANGEBYSCORE	Leaderboards, priority queues
Pub/Sub	PUBLISH, SUBSCRIBE	Real-time messaging
Streams	XADD, XREAD	Event logs, Kafka-lite

Redis for rate limiting

def is_rate_limited(user_id, limit=100, window=60):
    key = f"rate:{user_id}"
    count = redis.incr(key)
    if count == 1:
        redis.expire(key, window)  # set expiry on first request
    return count > limit

Redis Cluster

Horizontal scaling for Redis: data automatically sharded across nodes using consistent hashing (16,384 hash slots). Supports replica nodes per shard for HA.

Caching in Practice: A Real Example

Scenario: E-commerce product page receiving 50,000 requests/minute.

Product page request flow:

1. Browser checks its own cache (Cache-Control header)
   HIT → serve from browser in 0ms

2. CDN edge (Cloudflare) checks its cache
   HIT → serve from CDN in 5ms

3. App server checks Redis
   HIT → return in 1ms
   MISS
    ↓
4. Query PostgreSQL with read replica
   → takes 15–80ms

5. Store in Redis with TTL=300s (5 min)

6. Return response + set Cache-Control header for CDN/browser

Cache strategy per data type:

Data	Cache location	TTL	Invalidation
Product details	Redis + CDN	5–30 min	On product update
User session	Redis	24 hours	On logout
Homepage recommendations	Redis	10 min	TTL only
User’s own cart	Redis	72 hours	On cart update
Static assets (JS/CSS)	CDN	1 year (versioned URL)	Deploy new version with new URL

How would you add caching to a system?

Step 1: Identify the hot path.

“What are the most frequently accessed data pieces? Product listings, user sessions, search results?”

Step 2: Choose strategy.

“I’d use cache-aside with Redis. The app checks Redis first; on miss, queries the DB and populates Redis with a 5-minute TTL.”

Step 3: Address invalidation.

“On product update, we delete the Redis key. On next read, fresh data populates the cache.”

Step 4: Address failure.

“If Redis goes down, the app falls through to the DB — degraded performance but not an outage. Redis persistence is configured so warm restart restores the cache quickly.”

Step 5: Address stampede.

“For very high traffic keys, we use a mutex lock on cache miss to prevent thundering herd.”

Flashcards

Q: What is cache-aside (lazy loading)?

App checks cache first; on miss, fetches from DB and populates cache. Most common pattern.

Q: What is write-through caching?

Every write goes to both cache and DB synchronously. Cache is always consistent; writes are slower.

Q: What is write-behind (write-back) caching?

Write to cache immediately; async write to DB later. Fastest writes, risk of data loss.

Q: What is a cache stampede?

When a popular cached key expires and many requests simultaneously miss the cache and overload the DB.

Q: What is cache penetration?

Requests for keys that don’t exist in DB bypass the cache repeatedly. Solution: cache null values or use Bloom filter.

Q: What is LRU eviction?

When cache is full, evict the key not accessed for the longest time. Default choice for most systems.

Q: What is cache avalanche?

Many cache keys expire simultaneously, causing a traffic spike to the DB. Solution: add random jitter to TTLs.
