Scaling Systems: Performance, Bottlenecks & Capacity Planning

The Story: How a City Grows

A village of 100 becomes a town of 10,000, then a city of 1M. Each stage of growth forces infrastructure changes:

• Village: one well for water (vertical)
• Town: municipal water system (shared infrastructure)
• City: water towers in every district (distributed)

Your system follows the same growth curve. The architecture that works at 1K users breaks at 100K. What works at 100K breaks at 10M. The skill is knowing which bottleneck to fix at each stage.

---

Identifying Bottlenecks

Bottleneck: The single constraint that limits overall system throughput. Fix everything else — it doesn’t matter. Fix the bottleneck — everything improves.

The Four Classic Bottlenecks

[Network] → [App Server: CPU/Memory] → [Database: I/O/Locks] → [Disk]

How to find yours:

# CPU bottleneck
top                              # CPU > 90% consistently
vmstat 1 10                      # us (user), sy (system) columns

# Memory bottleneck
free -h                          # check available memory
vmstat 1                         # si/so (swap in/out) — swap usage = memory problem

# I/O bottleneck
iostat -x 1 10                   # %util column → disk saturation
iotop                            # which processes are I/O heavy

# Network bottleneck
nethogs                          # per-process network usage
ss -s                            # socket statistics
netstat -i                       # interface stats

# Database bottleneck
SHOW PROCESSLIST;                # MySQL — what queries are running
SELECT * FROM pg_stat_activity;  # PostgreSQL
EXPLAIN ANALYZE SELECT ...;      # query plan + actual timing

---

The Scalability Toolkit

Horizontal Scaling (Scale Out)

Add more servers. The fundamental answer to traffic growth.

Before: [Server: handles 1K RPS]
After:  [Server][Server][Server][Server] behind LB → handles 4K RPS

Prerequisites:

1. App must be stateless (no session on server)
2. Shared state in external systems (Redis, DB)
3. Load balancer in front

Database Read Replicas

Your DB is the bottleneck. 90% of queries are reads. Add read replicas.

All writes → [Primary DB]
                 ↓ replication
All reads  → [Replica 1] [Replica 2] [Replica 3]

Application code:

# Write connection pool
write_db = create_engine("postgresql://primary:5432/db")

# Read connection pool (round-robin across replicas)
read_db = create_engine("postgresql://replica1,replica2,replica3/db", execution_options={ "postgresql_readonly": True })

def get_user(user_id):
    return read_db.execute("SELECT * FROM users WHERE id = ?", user_id)

def update_user(user_id, data):
    write_db.execute("UPDATE users SET ... WHERE id = ?", user_id)

Connection Pooling

Problem: Each DB connection is expensive (~memory, TCP handshake). App opens connection per request → 10K concurrent requests → 10K connections → DB melts.

Solution: Connection pool — maintain a pool of open connections, reuse them.

# SQLAlchemy connection pool
engine = create_engine(
    "postgresql://localhost/db",
    pool_size=20,                # maintain 20 connections
    max_overflow=10,             # allow 10 more under load
    pool_timeout=30,             # wait 30s for connection before error
    pool_recycle=3600            # recycle connections every hour (prevents stale)
)

Tools: PgBouncer (PostgreSQL connection pooler — handles 10K+ connections down to 100 DB connections), ProxySQL (MySQL).

Async I/O

Synchronous: Thread waits while waiting for DB/API response. Thread blocked. 100 concurrent requests = 100 threads.

Async: Thread registers callback for I/O completion, moves on. One thread handles thousands of concurrent I/O-bound operations.

# Sync — blocks per request
def get_user_sync(user_id):
    user = db.query("SELECT...")   # thread blocks here
    posts = api.get_posts(user_id) # thread blocks here
    return merge(user, posts)

# Async — both I/O operations run concurrently
async def get_user_async(user_id):
    user, posts = await asyncio.gather(
        db.async_query("SELECT..."),
        api.async_get_posts(user_id)
    )
    return merge(user, posts)

Frameworks: Python (FastAPI, asyncio), Node.js (event loop), Go (goroutines), Java (reactive streams).

---

Database Performance Optimization

Query Optimization

EXPLAIN ANALYZE — your best friend:

EXPLAIN ANALYZE
SELECT u.name, COUNT(o.id) as order_count
FROM users u
JOIN orders o ON u.id = o.user_id
WHERE u.created_at > '2026-06-01'
GROUP BY u.id, u.name;

Output:

Gather (cost=... rows=...)
  → Hash Join (...)
      → Seq Scan on users (cost=...) ← RED FLAG: full table scan
      → Hash (...)
          → Seq Scan on orders (...)
Planning time: 1.2ms
Execution time: 2847ms  ← WAY too slow

After adding index on users.created_at:

Index Scan on users using idx_created_at (...)
Execution time: 12ms  ← 237× faster

N+1 Query Problem

The silent killer of application performance.

# N+1 problem: 1 query for users + N queries for each user's orders
users = db.query("SELECT * FROM users LIMIT 100")  # 1 query
for user in users:
    orders = db.query("SELECT * FROM orders WHERE user_id = ?", user.id)  # 100 queries
    # 101 total queries instead of 1

# Fixed: JOIN or batch fetch
users_with_orders = db.query("""
    SELECT u.*, o.id as order_id, o.amount
    FROM users u
    LEFT JOIN orders o ON u.id = o.user_id
    WHERE u.id IN (...)
""")  # 1 query

ORMs make this easy to do by accident. Always check query counts in development.

Database Partitioning (Table Partitioning)

Split a large table into smaller physical partitions — within the same DB.

-- Partition orders by year
CREATE TABLE orders (
    id BIGINT,
    user_id BIGINT,
    created_at TIMESTAMP,
    amount DECIMAL
) PARTITION BY RANGE (created_at);

CREATE TABLE orders_2022 PARTITION OF orders
    FOR VALUES FROM ('2022-01-01') TO ('2023-01-01');
CREATE TABLE orders_2023 PARTITION OF orders
    FOR VALUES FROM ('2023-01-01') TO ('2024-01-01');
CREATE TABLE orders_2024 PARTITION OF orders
    FOR VALUES FROM ('2024-01-01') TO ('2025-01-01');

Query WHERE created_at > '2024-01-01' only scans orders_2024 — massive performance gain for time-series data.

---

Application Performance

The Performance Measurement Hierarchy

p50 latency  : median — 50% of requests are faster than this
p95 latency  : 95% of requests are faster than this
p99 latency  : 99% of requests are faster than this
p999 latency : 99.9% of requests are faster than this (the "long tail")

Always use percentiles, never averages. A p50 of 50ms is fine. A p99 of 5000ms means 1% of users have terrible experience.

The long tail problem: Tail latencies compound. If a page makes 10 parallel API calls each with p99=500ms, the page p99 = probability that at least one is slow = much worse than 500ms.

Concurrency Models

Multi-threading (Python/Java):

1 process → N threads
Each thread handles 1 request
Good for: CPU-bound workloads
Problem: Thread overhead, GIL in Python limits CPU parallelism

Event loop (Node.js, asyncio):

1 thread → event loop → callbacks
Handles thousands of concurrent I/O-bound operations
Good for: I/O-bound (API calls, DB queries)
Problem: CPU-bound tasks block the event loop

Multi-process (Gunicorn, Uvicorn workers):

N worker processes, each with their own memory
Each worker handles 1 (or more with async) request at a time
Good for: Python apps (bypasses GIL), isolation

Goroutines (Go):

M goroutines on N OS threads (M:N threading)
Thousands of goroutines with minimal overhead (~2KB each vs 1MB for OS threads)
Good for: massive concurrency with both CPU and I/O workloads

Lazy Loading vs Eager Loading

# Eager loading: load everything upfront
user = User.query.options(
    joinedload(User.orders),
    joinedload(User.preferences)
).get(user_id)
# One query, but loads data you may not use

# Lazy loading: load only when needed
user = User.query.get(user_id)  # fast
if need_orders:
    orders = user.orders  # triggers query only when needed

General rule: Use eager loading when you know you’ll need related data. Use lazy loading for optional data.

---

Capacity Planning

Back-of-envelope calculations tell you what resources you need before you build.

Example: Design Instagram’s photo storage

Assumptions:

Users: 500M daily active users
10% post a photo/day = 50M new photos/day
Average photo size: 3MB (original)
Multiple versions stored (thumbnail, medium, full): 5MB total per photo
System lifetime: 10 years

Storage:

Daily: 50M × 5MB = 250TB/day
Annual: 250TB × 365 = ~90PB/year
10 years: ~900PB ≈ 1 exabyte

Read traffic:

200M users view 100 photos/day
= 20B photo views/day
= 20B / 86,400s ≈ 230,000 reads/second

Bandwidth:

Served size ≈ 0.5MB average (thumbnail + medium)
230,000 RPS × 0.5MB = 115GB/s outbound bandwidth
→ This is the CDN's job — origin serves far less

Servers:

Assume each server handles 1000 photo read RPS with caching
230,000 / 1000 ≈ 230 servers (minimum, before redundancy)
With N+1 redundancy and headroom: ~500 app servers

The Capacity Planning Formula

Required servers = (RPS × average_request_duration_seconds) / target_CPU_utilization

Example:
RPS = 10,000
Average request duration = 50ms = 0.05s
Target CPU utilization = 70%

Required servers = (10,000 × 0.05) / 0.7 = 500 / 0.7 ≈ 715 servers

---

Performance Anti-Patterns

Synchronous Chain of Services

❌ User request triggers:
Service A (50ms) → Service B (30ms) → Service C (40ms) → Service D (25ms)
Total: 145ms latency, 4× failure surface area

✅ Parallelise independent calls:
Service A (50ms) ─┐
Service B (30ms)  ├─ all parallel → 50ms (longest one)
Service C (40ms) ─┘
Then Service D (depends on above): +25ms
Total: 75ms, better failure isolation

Missing Database Indexes

❌ Query runs fine in development (100 rows)
✅ Same query takes 30 seconds in production (10M rows)
   → Add EXPLAIN ANALYZE to every non-trivial query
   → Index every column you filter, sort, or join on

Loading Too Much Data

❌ SELECT * FROM users WHERE ...    → returns 50 columns, uses 200 bytes/row
✅ SELECT id, name, email WHERE ... → returns only needed columns, 40 bytes/row

❌ Load all 10M records, filter in app code
✅ Filter in SQL WHERE clause — let DB do the work

❌ Load all 10K orders for dashboard "total revenue" calculation
✅ SELECT SUM(amount) FROM orders — aggregate in DB

Not Using Bulk Operations

❌ for user in users:     # 10,000 individual INSERT statements
       db.insert(user)

✅ db.bulk_insert(users)  # 1 INSERT with 10,000 rows
   # 100× faster

---

Flashcards

Q: How do you scale a system from 1K to 10M users?

At 1K users: single server is fine.

At 10K: add caching (Redis) and a read replica — database is usually the first bottleneck.

At 100K: horizontal scaling of app servers behind a load balancer, CDN for static assets.

At 1M: database sharding or migration to Cassandra for high-write workloads, message queues to decouple heavy operations.

At 10M: multi-region deployment, aggressive caching, specialised storage per use case (search → Elasticsearch, analytics → ClickHouse), potential microservices extraction for independently-scaling components.

Q: What is the N+1 query problem?

Fetching N records and then making 1 additional query per record — totaling N+1 queries. Fix with JOINs or batch fetching.

Q: Why use percentiles instead of averages for latency?

Averages hide the “long tail” — a few very slow requests don’t move the average much but represent real user suffering. p99 shows what 1% of users experience.

Q: What is connection pooling?

Maintaining a pool of reusable DB connections instead of creating/destroying per request. Dramatically reduces DB overhead.

Q: What is the difference between vertical and horizontal scaling?

Vertical = bigger machine (more CPU/RAM). Horizontal = more machines. Horizontal is preferred at scale but requires stateless apps.

Q: What does EXPLAIN ANALYZE do in SQL?

Shows the query execution plan with actual timing — reveals full table scans, missing indexes, and where time is spent.
