The Big Picture of System Design
- system-design
- backend
- architecture
System design is one of those skills that separates good engineers from great ones. You can write clean code — but can your system handle 10 users? 10,000 users? 10 million users? This series is about building that intuition from scratch.
The One Analogy That Rules Them All
Your application is a city.
If you understand this analogy, system design becomes much easier to reason about. This mental model will stay with you across every system you design.
| System Design Concept | City Analogy | Memory Anchor |
|---|---|---|
| Single server | A house | One person doing everything |
| Load balancer | Traffic cop at the city gate | Distributes cars across roads |
| Application servers | Office buildings | Where the actual work happens |
| Database | The city vault / records room | Permanent, authoritative storage |
| Cache | Sticky note on your desk | Fast, temporary, nearby |
| CDN | Local shops in every neighbourhood | Content near where users live |
| Message queue | The city post office | Drop work, processed later |
| DNS | City address directory | Names → IP addresses |
| API Gateway | City reception desk | One entry point, routes to departments |
What is System Design?
System design is:
Designing the architecture, components, and data flow of a system to meet requirements at scale.
Think of the evolution:
- Junior dev → “Does this code work?”
- Mid-level dev → “Does this work reliably?”
- Senior dev → “Will this work at scale?”
- System designer → “How do we build this so it doesn’t break under real-world conditions?”
How Real Systems Evolve
No system starts “distributed.” Everything begins simple — and grows.
Stage 1: [User] → [Server + DB]
Stage 2: [User] → [App Server] → [DB]
Stage 3: [User] → [App Server] → [Cache] → [DB]
Stage 4: [User] → [LB] → [Multiple App Servers] → [Cache] → [DB]
Stage 5: [CDN] handles static content
Stage 6: [Queue + Workers] handle async tasks
Stage 7: [DB Replication] for scaling readsRule:
👉 Only add complexity when a bottleneck forces you to.
Core Qualities You Design For
Every system design decision optimizes for one (or more) of these:
| Quality | Meaning | City Analogy |
|---|---|---|
| Scalability | Handle increasing load | City can grow — add buildings and roads |
| Availability | System is up and serving | City hall never closes |
| Reliability | Correct results consistently | Records are always accurate |
| Latency | Time for one request | How fast your food arrives |
| Throughput | Requests per second | How many orders the kitchen handles/hour |
| Consistency | All users see the same data | Everyone reading the same city map version |
| Fault tolerance | Works when components fail | City functions despite one grid going down |
Latency Numbers You Should Know
These help you reason about bottlenecks:
| Operation | Latency |
|---|---|
| L1 cache | ~0.5 ns |
| RAM (Main memory) | ~100 ns |
| SSD | ~100 µs |
| Network (same DC) | ~0.5 ms |
| HDD | ~10 ms |
| Cross-continent network | ~150 ms |
👉 Key insight:
Network calls are expensive. Disk is slow. Memory is fast. Cache is king.
Horizontal vs Vertical Scaling
| Vertical Scaling (Scale Up) | Horizontal Scaling (Scale Out) |
|---|---|
| Increase machine power (CPU, RAM) | Add more machines |
| Simple to implement | Requires stateless architecture |
| Has a limit | Highly scalable |
| Single point of failure | No single point of failure |
Example:
Vertical: [2 CPU, 4GB] → [32 CPU, 128GB] ← one machine gets bigger
Horizontal: [Server] → [Server][Server][Server] ← more machines added👉 Modern systems prefer horizontal scaling.
Stateful vs Stateless Systems
| Stateful Systems | Stateless Systems |
|---|---|
| Server stores session | No session stored on server |
| User must hit same server | Any server can handle any request |
| Breaks scalability | Enables scaling |
👉 Any server can handle any request → enables scaling.
The RESHADED Framework (For Interviews)
Use this to structure any system design answer:
| Letter | Stands for | What to address |
|---|---|---|
| R | Requirements | Functional + non-functional |
| E | Estimation | Traffic, storage, bandwidth |
| S | Storage | SQL vs NoSQL, schema |
| H | High-level design | Components + connections |
| A | APIs | Key endpoints |
| D | Deep dives | Bottlenecks, scaling |
| E | Edge cases | Failure modes |
| D | Done | Summarise trade-offs |
This alone can level up the interview performance massively.
Quick Recap
- System design is about scale, reliability, and architecture
- Start simple → evolve gradually
- Think in terms of components, not code
- Prefer stateless systems for scalability
- Understand trade-offs — there’s no perfect system
Flashcards
Q: What are the core system qualities?
Scalability, Availability, Reliability, Latency, Throughput, Consistency, Fault tolerance
Q: Vertical vs Horizontal scaling?
Vertical = bigger machine
Horizontal = more machines
Q: What makes a system stateless?
No session stored on server
Q: Why is caching important?
Because memory is orders of magnitude faster than disk/network
